MYZ-series automatic double role slime filter press

I. Introduction:
Automatic dual role slime MYZ-series filter press is the Xuzhou TIANKE Machinery Manufacturing Co., Ltd. newly developed high-tech products. This machine adopts the mine explosion PLC automatic control system, machine, electrical, hydraulic integration design, a key operation, automatic operation, the latest technology of solid-liquid separation treatment of coal mine slime generation product. The machine except for underground slime treatment, and any other materials can also be used for solid-liquid separation.
Second, the main features:
A one-button operation, automatic control: the mine explosion PLC automatic control system, automatic clamping, feeding, filtration, discharging, in order to achieve unattended, greatly reduce labor costs and improve the safety of the underground work.
2 dual workspace operations: filter press for dual workspace structure, pressure filtration, dewatering, discharge and continuous operation, work efficiency increased by 1.5-2 times.
Native automatic unloading and automatic loading or connection with the belts, scraper, the material in transport.
4 device with full hydraulic power, PLC program control, various technical parameters can be set and automatic control based on pressure filtration requirements.
Equipped with a filter press pump, constant pressure into the material, to avoid the mud leakage phenomenon, to extend the life of the filter cloth, the pressure filtration efficiency, to ensure the safety of the equipment, reliable operation.
The device structure is simple, small footprint, and do not do the foundation.　　Third, the technical parameters:

No.	Project	Unit	Model
No.	Project	Unit	MYZ-900	MYZ-1000	MYZ-1250
1	Control box voltageAC	V	380/660/1140	380/660/1140	380/660/1140
2	Production capacity (dry slime)	t/h	5-8	10-15	15-20
3	Total power	KW	18.5	22	30
4	The filter plate specifications (LWH)	㎜	900×900×60	1000×1000×60	1250×1250×65
5	Filtration area	㎡	90	120	160
6	Filtration pressure	MPa	0.6～1.0	0.6～1.0	0.6～1.0
